Used Ditch Witch Subsite 750 Tracker (set). Stock number: Z826

Brand: Ditch Witch

  • $ 6,000.00



Apply for financing. Low monthly payments.

We accept trade-ins:

We make trades local dealers cannot match. Trade up, trade down with cash-back, or sell your used equipment. Contact us to see what we can do for you!


We offer 100 day warranty. Take the stress out of buying used equipment.

Package Includes:

***Stand is not included in package. Cost is an additional $100 if available***

Next-day delivery within USA:

Avoid downtime. Request one-day delivery and get locating package the next day.

We ship worldwide:

We ship worldwide and offer flexible international shipping rates. We work with the freight forwarder of your choice or help you to choose the most suitable one.

Transmitter compatibility:

    Ditch Witch Subsite TK750 Locator Specifications:


    12.75 in (32.4 cm)


    31.5 in (80 cm)


    6 in (15.2 cm)

    Operating Weight

    5.5 lb (2.5 kg)

    Operating Temperature Range

    -4°F to 122°F (-20°C to 50°C)

    Antenna Configuration


    Operating Modes:

    • 12K beacon
    • 29K beacon
    • 60 Hz power
    • 50 Hz power
    • 8 kHz line (active)

    2 Radio Frequencies
    Maximum Locating Range:

    • Beacon: 0.75 ft - 99 ft 11 in (22.9 cm - 30 m)
    • Line: 0-10 ft (0-3 m)

    Depth Calibration Tolerances:

    • ±4 in (10 cm) at 10 ft (3 m)
    • ±5% from 10-20 ft (3-6.1 m)
    • ±10% beyond 20 ft (6.1 m)

    Line Location Tolerances:

    • Active mode: ±3% at 10 ft (3 m)
    • Passive mode: ±5% at 6 ft (1.8 m); ±10% at 10 ft (3 m)

    Batteries: 6 C cell alkaline
    Battery Life: approximately 20 hours
    Battery Saver: unit shuts off after 5 minutes if no key is pressed

    Ditch Witch Subsite 750 Remote Display Specifications:

    Remote Display w/o Case

    Radio Type

    2 channel, dual conversion, narrow-band FM

    Frequency Range

    420 – 470 mHz


    -110dbm for 12db SINAD (typical)

    Operating Weight

    2.5 lbs (1.1 kg)

    Power Input

    6.5 V dc – 16 V dc at approx. 150ma

    Interface Connectors

    DB-15P (D-series sub-miniature male)


    Remote Display w/ Case


    Operating Weight

    6.5 lbs (3 kg)


    6 C-Cell alkaline


    MS5015 (7 pin)


    TNC female

    Battery Life

    20 hours


    In stock and job-site ready. Package components available for individual sale. Overnight shipping available.

    Stock number: #Z826
