Kaelus iPA-0707A PIM Passive Intermodulation Analyzer. Stock number: K0707A

Original price $ 18,000.00 - Original price $ 18,000.00
Original price
$ 18,000.00
$ 18,000.00 - $ 18,000.00
Current price $ 18,000.00

Package includes:

  • Kaelus iPA-0707A Passive Intermodulation Analyzer
  • 4GB SD Memory Card
  • USB PC Interface Cable
  • AC Adapter/Charger
  • Power Cord
  • Hard Carrying Case (G)

Description:

The iPA Series Passive Intermodulation (PIM) analyzer is the first battery powered PIM Test Analyzer versatile enough to support multiple test scenarios such as testing at the top of the tower, base of tower, roof top and in-building for DAS systems. This IEC compliant 20W, rugged, battery operated design includes a tablet computer in a ruggedized case for remote control. This allows hands-free dynamic testing that is safe and convenient. Add the optional Range to Fault (RTF) module to quickly identify the location of PIM and Return Loss sources.

Financing:

Apply for financing. Low monthly payments.

We accept trade-ins:

We make trades local dealers cannot match. Trade up, trade down with cash-back, or sell your used equipment. Contact us to see what we can do for you!

Warranty:

We offer 30 day warranty. Take the stress out of buying used equipment.

    Next-day delivery within USA:

    Avoid downtime. Request one-day delivery and get remote display the next day.

    We ship worldwide:

    We ship worldwide and offer flexible international shipping rates. We work with the freight forwarder of your choice or help you to choose the most suitable one.

    Kaelus iPA-0707A  specifications:

    SYSTEM
    Measurement method Reverse (reflected) PIM, 3rd and 5th order.
    Residual PIM < -117dBm/-160dBc maximum (<-125dBm/-168dBc typical)
    Interface ports 1x RF output (7-16 DIN female), 1x USB 2.0 Host, 1x USB 2.0 Slave, 1x SD 1x monitor port (SMB female), 1x SMA-RP (Wi-Fi external antenna)
    User interface Local - touch screen display 4.3in (109mm) Remote - tablet computer (included), any Wi-Fi enabled user device with web browser
    Return loss alarm Automatic detection and shut down when high RL is detected
    TRANSMITTER
    Transmit frequencies 728-731.5MHz
    Frequency increment 100kHz
    Frequency accuracy ± 5ppm maximum, aging ± 1ppm maximum after first year
    Power per tone (adjustable) 0.1 to 20W (+20 to +43dBm in 1dB increments)
    Power accuracy (per tone) ± 0.5dB maximum
    RECEIVER
    Receive band (100kHz steps) 698-716MHz 776-802MHz
    Measurement noise floor < -128dBm
    Measurement range -50dBm to -128dBm
    ELECTRICAL
    Battery power 25.9 VDC, 2600 mAh, 67Wh Lithium Ion battery packs (removable)
    Battery operating time Depends on usage, 2 hr minimum per battery pack
    Battery charger Output: 29.4 VDC, 1.2 Amp
    MECHANICAL
    Dimensions H x D x W 369 x 160 x 240mm | 14.5 x 6.3 x 9.4in
    Weight 12kg | 26lbs
    ENVIRONMENTAL
    Temperature range -10ºC to +45ºC | +14°F to +113°F
    Ingress protection IP54. IP67 when enclosed in optional hard case
    Operational humidity 5% to 95% RH non-condensing
    Storage temperature range -10°C to +60°C | +14°F to +140°F
    Mechanical shock 40G shock rating



    In stock and job-site ready. Package components available for individual sale. Overnight shipping available.
