Used EXFO MAX-715B-M1-EA-RF 1310/1550 nm Fiber Optic Tester. Stock number: E5
- Used EXFO MAX-715B-M1-EA-RF SingleMode Fiber IOLM
- Used AC Adapter/Charger
The MaxTester 715B iOLM is optimized for the point-to-point testing and troubleshooting of FTTx architectures, and is ideal for testing short fibers (e.g., inside a CO environment or at FTTA/DAS network installations).
Apply for financing. Low monthly payments.
We accept trade-ins:
We make trades local dealers cannot match. Trade up, trade down with cash-back, or sell your used equipment. Contact us to see what we can do for you!
We offer 30 day warranty. Take the stress out of buying used equipment.
Next-day delivery within USA:
Avoid downtime. Request one-day delivery and get remote display the next day.
We ship worldwide:
We ship worldwide and offer flexible international shipping rates. We work with the freight forwarder of your choice or help you to choose the most suitable one.
7-in (178-mm) outdoor-enhanced touchscreen,
800 x 480 TFT
Two USB 2.0 ports
RJ45 LAN 10/100 Mbit/s
2 GB internal memory
(20 000 OTDR traces, typical)
Rechargeable lithium-polymer battery
12 hours of operation as per Telcordia (Bellcore)
Power supply AC/DC adapter, input 100-240 VAC,
50-60 Hz, 9-16 V DCIN
15 Watts minimum
|Wavelength (nm)||1310 ± 30/1550 ± 30|
|SM live port built-in filter||
1625 nm: highpass >1595 nm isolation
>50 dB from 1270 nm to 1585 nm
|Dynamic range (dB)||30|
|Event dead zone (m)||1|
|Attenuation dead zone (m)||4|
|PON dead zone (m)||35|
|Distance range (km)||0.1 to 160|
|Pulse width (ns)||5 to 20 000|
|Loss threshold (dB)||0.01|
|Loss resolution (dB)||0.001|
|Sampling resolution (m)||0.04 to 5|
|Sampling points||Up to 256 000|
|Distance uncertainty (m)||
±(0.75 + 0.0025 % x distance +
|Measurement time||User-defined (maximum: 60 minutes)|
|Reflectance accuracy (dB)||±2|
|Typical real-time refresh (Hz)||3|
In stock and job-site ready. Package components available for individual sale. Overnight shipping available.
