Mag X PRO System: Maximum Range, Maximum Confidence

Our Most Powerful Locating System Yet

The Mag X PRO pairs our flagship receiver with the new Echo 75XF transmitter to tackle the toughest HDD jobs. More range, less interference, and effortless data logging—built for crews who push limits daily.

Dual 3D Solid Core Antennas – Double the Reach

Two advanced antennas deliver 2× the range on sub-kHz frequencies, giving you reliable signal lock even on deep bores or congested job sites. Rebar Ready technology cuts through passive interference from buried steel and rebar, so you get clean readings where other locators struggle. Seamlessly switch between Bore-To steering and Walkover mode as conditions change.

One-Touch Data Logging

Capture every rod's pitch, depth, and position with a single tap. View your bore in Rodwise or Chart formats, add or edit utility crossings on the fly, and email reports or sync to UM Maps directly from the display—no extra software required.

Echo 75XF 19″ Transmitter – Power to Spare

Choose your output based on the job:

• Low Power: 114 ft range / 100 hrs battery life

• Medium Power: 180 ft range / 60 hrs battery life

• High Power: 278 ft range / 11 hrs battery life

Built for the Field

• Weight: 38 lbs | Dimensions: 29 × 9 × 13 in

• Temp Range: -4°F to 140°F (-20°C to 60°C)

• Waterproof: IP65-rated

• Battery: 12.5V Li-ion – 50 hours runtime

• 16 Frequencies: .325 kHz – 41 kHz

• Telemetry: 4 channels up to 3,000 ft (900m)

Compatible Transmitters

Echo XMini / Echo 50 / Echo 50x / Echo 50XF / Echo 60 / Echo 75XF / Echo 90 / Echo 110
