Available only in Tampa Bay Florida

Package includes:

• Underground Magnetics MAG X GEO Locator
• Android-based color touchscreen remote display
• External Mag X GEO GPS/RTK antenna

Mag X GEO System: GPS-Powered Precision for HDD

Drill Smarter with Real-Time Positioning

The Mag X GEO builds on our trusted locator platform with integrated RTK-GPS and a 7-inch color touchscreen. It gives your crew aerial mapping, side-profile charts, and rod-by-rod data—all in one rugged package. Less guesswork, less rework, more accuracy.

Intuitive Control, Instant Access

A 7-inch touchscreen paired with tactile multi-function buttons keeps key tools just a click away. Fly-up menus let you switch between views and steering modes without losing your rhythm on the job.

Log as You Go – No Backtracking

Capture pitch, depth, temperature, roll, and GPS coordinates for every rod automatically. Mark utility crossings with type, GPS location, and depth the moment you expose them. Review progress in three views: Overhead Map, Side-Profile Chart, and Rod Table—so you stay on track from start to finish.

Guidance Tools That Keep You On Target

• Dropline – GPS-guided vertical reference for depth control.

• Pitch Guide – helps maintain consistent entry angle.

• Bore-To – projects depth and aligns you with the target.

RTK-Enabled GPS – 1–3 cm Accuracy

Integrated GPS with RTK support delivers centimeter-level positioning, including elevation tracking. Every rod is georeferenced with precision—critical when working near congested utilities.

Reporting Made Simple

Generate, email, or sync reports directly from the receiver. Add utility crossing data, monitor project progress in real time, and eliminate post-job paperwork headaches.

Built for the Field

• Weight: 38 lbs | Dimensions: 29 × 9 × 14 in

• Temp Range: -4°F to 140°F (-20°C to 60°C)

• Waterproof: IP65-rated

• Battery: 12.5V Li-ion – 15hrs (receiver) / 50hrs (display)

• Accuracy: ±5%

Telemetry That Reaches Further

Four radio channels deliver a solid link up to 3,000 ft (900m). Dual telemetry extends your range indefinitely over network connections—ideal for large-scale or remote jobs.

16 Frequencies – .325 kHz to 41 kHz

Cut through interference and adapt to any ground condition with a wide frequency selection.

Compatible Transmitters

Echo 110, Echo 50, Echo 50XF, Echo 60, Echo 70, Echo 75XF, Echo 90, Echo ST, Echo X-Mini.

Specifications:
